Bring up a Jetson TX2i

Where this stands

SpaceOS does not run on the Jetson TX2i today. No target profile ships for it, and the platform source lists the board under “Not currently supported” in its support matrix (docs/support-matrix.md).

The board was demonstrated under the OSIP T1 programme with the GPU in use. That is programme history, and the code does not carry it: Jetson, TX2i and TensorRT appear nowhere in the platform source, and none of the five shipped target profiles declares an accelerator of any kind.

The vendor flashing steps below are NVIDIA’s and they work. The SpaceOS half does not exist, so this page stops where L4T boots.

The NVIDIA Jetson TX2i is the industrial-grade variant of the Tegra X2 module, a hex-core ARM SoC (dual NVIDIA Denver + quad Cortex-A57) paired with a 256-core Pascal GPU. It is intended as a daemon install in the target matrix, for AI inference workloads that need on-board GPU acceleration.

NVIDIA Jetson TX2i: aarch64 with a Pascal GPU.

The Jetson developer carrier uses the standard firmware-and-root-filesystem flow. Custom carrier boards (Connect Tech, Auvidea, and similar) use the same flow with vendor-specific device-tree overlays.

Use the JetPack / L4T line that still supports TX2i in your vendor board support package. TX2i deployments usually stay on JetPack 4.x, because newer JetPack lines target later Jetson modules.

Hardware topology

• 2× NVIDIA Denver 2 cores + 4× ARM Cortex-A57.
• 256-core Pascal GPU with CUDA support and TensorRT runtime.
• 8 GB LPDDR4 memory, 32 GB eMMC, MIPI CSI camera lanes, multiple PCIe Gen 2 lanes.
• Industrial-temperature variant: −40 °C to +85 °C operating range, with no soldered-on parts that block flight qualification.

Flash a Linux image

NVIDIA ships JetPack for Jetson modules, an SDK Manager that bundles the board support package, Linux for Tegra (L4T), CUDA, cuDNN, and TensorRT.

Start from the vendor L4T image. A SpaceOS daemon install would need KVM turned on, the contiguous memory area sized for the workload, and a device access policy for the GPU nodes. SpaceOS ships no target overlay that does this, so those are kernel-configuration changes you make yourself.

Flash and configure the module:

1. Install NVIDIA SDK Manager on an x86_64 Linux host.
2. Place the TX2i module in recovery mode (jumper or button sequence; consult the carrier-board documentation).
3. Run SDK Manager and flash the OS image and components.

Boot and verify

After flashing, boot the module and log in with the credentials you created during the L4T install.

ls /dev/kvm                   # KVM enabled
nvidia-smi                    # GPU visible
cat /etc/nv_tegra_release     # L4T version

The intended arrangement gives container services (isolation: runc) the Pascal GPU through CUDA once the target grants the device nodes, and gives unikernel services the hardware acceleration delegation path. Both are design. The accelerator schema models a Gpu kind and carries signed grants, and no shipped profile declares a GPU, so nothing selects one today.

Selection criteria

Choose the TX2i when:

• Your workload is GPU-bound, such as object detection or segmentation.
• You can accept the +85 °C upper limit and the Pascal-era performance envelope.
• You need a self-contained module, where the carrier board is the only mission-specific hardware.

The VCK190 gives higher inference throughput on FPGA fabric. The Raspberry Pi 4B suits lower-power workloads that need no acceleration. All three are in development; the Raspberry Pi CM5 is the supported board to prove a workload on today.
